Zirconia spray nozzle (ZSN) is a type of nozzle used in industrial spray applications for coating, painting, or cleaning surfaces. It is made from zirconia ceramic, a high-strength and wear-resistant material that is ideal for use in harsh and abrasive environments.
The Zirconia spray nozzle operates by controlling the flow and direction of a liquid or gas through a narrow aperture, creating a fine mist or spray. The zirconia ceramic material used in the nozzle is able to withstand the high pressures and temperatures involved in spray applications, ensuring consistent and reliable performance over time.
One of the key advantages of using a Zirconia spray nozzle is its high wear resistance. The zirconia ceramic material is able to withstand the abrasive effects of the particles and chemicals involved in spray applications, ensuring a long service life and minimizing downtime.
Another advantage of using Zirconia spray nozzles is their resistance to chemical attack. The zirconia ceramic is inert and non-reactive, making it suitable for use in a wide range of industrial and chemical applications where exposure to harsh chemicals and solvents is a concern.
Zirconia spray nozzles are also known for their precise spray pattern and uniform droplet size, which can improve the efficiency and quality of spray applications. Additionally, the high strength and thermal stability of zirconia ceramic make it well-suited for use in high-temperature and high-pressure spray applications.
Zirconia Spray Nozzle (ZSN) can pipe are superior to other materials in chemistry corrosion proof, wear resistance, and thermo stability and so on. Therefore, it is widely used in bad conditions which metal or other materials could not be requirements.
Composition | Wt% | 94.8%ZrO2,5.2%Y2O3 |
Specific Density | g/cm3 | ≥6.0 |
Hardness (HV) | Kg/mm2 | ≥1250 |
Bending Strength | MPa | 1150 |
Fracture Toughness | MPa.m1/2 | ≥9 |
Grain Size | μm | <0.5 |
Elastic Modules | GPa | 200 |
Thermal Conductivity | W/(m.K) | 3 |
Thermal Expansion Coefficient (20-400℃) | ×10-6m/℃(20-400℃) | 9.6 |
We will contact you as soon as possible!
Zirconia Spray Nozzle
